Mitsubishi Heavy Industries Avanti Plus 6kW Inverter Wall Split System Air Conditioner
Specifications
- Model Numbers Indoor: SRK60ZSXA-WF
- Model Numbers Outdoor: SRC60ZSXA-W
- Power Supply: 1 Phase 240V 50Hz
- Cooling Capacity: 6.1 (1.0–6.9)
- Heating Capacity: 6.8 (0.8–8.8)
- Heating Capacity (H2): 6.8
- Power Consumption Cooling: 1.71 (0.19–2.50)
- Power Consumption Heating: 1.65 (0.20–2.86)
- Max Power Consumption: 2.9 kW
- Running Current Cooling: 7.2 A
- Running Current Heating: 6.9 A
- Inrush / Max Current: 5.0 / 15.0 A
- EER: 3.57
- COP: 4.12
- Outdoor Sound Power: 65 dB(A)
- Indoor Sound Pressure: 48–41–33–22
- Outdoor Sound Pressure: 52
- Indoor Dimensions: 305 × 920 × 220 mm
- Outdoor Dimensions: 640 × 800(+71) × 290 mm
- Indoor Weight: 13 kg
- Outdoor Weight: 45 kg
- Airflow (l/s) Cooling: 272-223-148-90
- Airflow (l/s) Heating: 297-228-182-103
- Refrigerant: R32 – 1.3 kg
- Pre-charged Pipe Length: 15 m
- Pipe Size Liquid: Ø6.35 mm
- Pipe Size Gas: Ø12.7 mm
- Max Pipe Length: 30 m
- Max Height Difference: 20 m (O.U. above I.U.) / 20 m (O.U. below I.U.)
