Mitsubishi Heavy Industries Avanti Plus 5kW Inverter Wall Split System Air Conditioner
Specifications
- Model Numbers Indoor: SRK50ZSXA-WF
- Model Numbers Outdoor: SRC50ZSXA-W
- Power Supply: 1 Phase 240V 50Hz
- Cooling Capacity: 5.0 (1.0–6.2)
- Heating Capacity: 6.0 (0.8–8.2)
- Heating Capacity (H2): 6.0
- Power Consumption Cooling: 1.24 (0.19–1.90)
- Power Consumption Heating: 1.36 (0.20–2.46)
- Max Power Consumption: 2.9 kW
- Running Current Cooling: 5.2 A
- Running Current Heating: 5.7 A
- Inrush / Max Current: 5.1 / 15.0 A
- EER: 4.03
- COP: 4.41
- Outdoor Sound Power: 63 dB(A)
- Indoor Sound Pressure: 44–39–31–22
- Outdoor Sound Pressure: 51
- Indoor Dimensions: 305 × 920 × 220 mm
- Outdoor Dimensions: 640 × 800(+71) × 290 mm
- Indoor Weight: 13 kg
- Outdoor Weight: 45 kg
- Airflow (l/s) Cooling: 238-207-130-90
- Airflow (l/s) Heating: 288-238-163-103
- Refrigerant: R32 – 1.3 kg
- Pre-charged Pipe Length: 15 m
- Pipe Size Liquid: Ø6.35 mm
- Pipe Size Gas: Ø12.7 mm
- Max Pipe Length: 30 m
- Max Height Difference: 20 m (O.U. above I.U.) / 20 m (O.U. below I.U.)
