Mitsubishi Heavy Industries Avanti Plus 2kW Inverter Wall Split System Air Conditioner
Specifications
- Model Numbers Indoor: SRK20ZSXA-WF
- Model Numbers Outdoor: SRC20ZSXA-W
- Power Supply: 1 Phase 240V 50Hz
- Cooling (T1): 2.0 (0.9–3.4)
- Heating (H1): 2.7 (0.8–5.5)
- Heating (H2): 3.7
- Power Consumption (kW) Cooling: 0.31 (0.16–0.76)
- Power Consumption (kW) Heating: 0.47 (0.14–1.36)
- Maximum Power Consumption: 1.92 kW
- Running Current (A): Cooling: 1.7
- Running Current (A): Heating: 2.4
- Inrush / Max Current (A): 2.5 / 9.0
- EER: 6.45
- COP: 5.74
- Sound Power (Outdoor): 56 dB(A)
- Sound Pressure (Indoor): 38–31–24–19 dB(A)
- Sound Pressure (Outdoor): 43 dB(A)
- Dimensions: Indoor: 305 × 920 × 220 mm
- Dimensions: Outdoor: 640 × 800(+71) × 290 mm
- Indoor Weight: 13 kg
- Outdoor Weight: 43 kg
- Airflow (l/s): Cooling: 188–152–100–83
- Airflow (l/s): Heating: 203–172–120–90
- Refrigerant: R32 – 1.2 kg
- Pre-charged Pipe Length: 15 m
- Pipe Size Liquid: Ø6.35 mm
- Pipe Size Gas: Ø9.52 mm
- Max Pipe Length: 25 m
- Max Height Difference: 15 m (O.U. above I.U.) / 15 m (O.U. below I.U.)
