Mitsubishi Heavy Industries Avanti Plus 3.5kW Inverter Wall Split System Air Conditioner
Specifications
- Model Numbers Indoor: SRK35ZSXA-WF
- Model Numbers Outdoor: SRC35ZSXA-W
- Power Supply: 1 Phase 240V 50Hz
- Cooling Capacity: 3.5 (0.9–4.5)
- Heating Capacity: 4.3 (0.8–6.8)
- Heating (H2) Capacity: 4.7
- Power Consumption Cooling: 0.74 (0.16–1.27)
- Power Consumption Heating: 0.90 (0.14–1.87)
- Max Power Consumption: 1.92 kW
- Running Current Cooling: 3.4 A
- Running Current Heating: 4.1 A
- Inrush / Max Current: 4.3 / 9.0 A
- EER: 4.73
- COP: 4.78
- Outdoor Sound Power: 61 dB(A)
- Indoor Sound Pressure: 43–35–26–19
- Outdoor Sound Pressure: 48
- Dimensions Indoor: 305 × 920 × 220 mm
- Dimensions Outdoor: 640 × 800(+71) × 290 mm
- Indoor Weight: 13 kg
- Outdoor Weight: 43 kg
- Airflow (l/s) Cooling: 218-180-122-83
- Airflow (l/s) Heating: 232-197-143-90
- Refrigerant: R32 – 1.2 kg
- Pre-charged Pipe Length: 15 m
- Pipe Size Liquid: Ø6.35 mm
- Pipe Size Gas: Ø9.52 mm
- Max Pipe Length: 25 m
- Max Height Difference: 15 m (O.U. above I.U.) / 15 m (O.U. below I.U.)
