Fujitsu 7.1kW Inverter Wall Split System Air Conditioner
Specifications
- INDOOR UNIT: ASTH24KMTD
- OUTDOOR UNIT: AOTH24KMTD
- Operation Type: Reverse Cycle
- Power Source V/Ph/Hz: 230 / 1 / 50
- Cooling Capacity kW (Rated (Min - Max)): 7.10 (1.1 - 8.3)
- Heating Capacity kW (Rated (Min - Max)): 8.00 (1.1 - 10.1)
- Input Power Cooling kW (Rated (Min - Max)): 2.08 (0.24 - 3.15)
- Input Power Heating kW (Rated (Min - Max)): 1.91 (0.14 - 3.17)
- EER: 3.41
- COP: 4.19
- Cooling Residential kW (Hot / Average / Cold): 5.344 / 5.094 / 5.481
- Heating Residential kW (Hot / Average / Cold): 4.819 / 4.265 / 3.586
- Running Current amps (Cooling / Heating): 9.3 / 8.7
- Moisture Removal l/hr: 2.7
- Indoor Sound Pressure Cooling dBA (High / Quiet): 49 / 29
- Indoor Sound Pressure Heating dBA (High / Quiet): 49 / 29
- Outdoor Sound Pressure dBA (Cooling / Heating): 54 / 53
- Outdoor Sound Power dBA: 66
- Air Circulation (Indoor - High Fan) Cooling l/sec: 325
- Air Circulation (Indoor - High Fan) Heating l/sec: 331
- Indoor Unit Dimensions mm (Height x Width x Depth): 280 x 980 x 240
- Indoor Unit Weight kg: 12.50
- Outdoor Unit Dimensions mm (Height x Width x Depth): 716 x 820 x 315
- Outdoor Unit Weight kg: 42.00
- Piping Connects mm Ø (Liquid / Gas): 6.35 / 12.7
- Pipe Length m (Max (Precharged)): 30 (15)
- Max Height Difference m: 25
- Operation Range Cooling °CDB (Min to Max): -10 to 50
- Operation Range Heating °CDB (Min to Max): -15 to 24
- Refrigerant Type: R32
- Refrigerant Amount g: 1,270
- UART Communication: Yes
- UART Communication Port: 2 Ports - CN65, CN75
