Fujitsu 6kW Inverter Wall Split System Air Conditioner
Specifications
- INDOOR UNIT: ASTH22KMTD
- OUTDOOR UNIT: AOTH22KMTD
- Operation Type: Reverse Cycle
- Power Source V/Ph/Hz: 230 / 1 / 50
- Cooling Capacity kW (Rated (Min – Max)): 6.00 (1.1 – 7.5)
- Heating Capacity kW (Rated (Min – Max)): 7.20 (1.1 – 9.4)
- Input Power Cooling kW (Rated (Min – Max)): 1.58 (0.24 – 2.72)
- Input Power Heating kW (Rated (Min – Max)): 1.7 (0.14 – 2.75)
- EER: 3.8
- COP: 4.24
- Cooling Residential kW (Hot / Average / Cold): 6.009 / 5.714 / 6.146
- Heating Residential kW (Hot / Average / Cold): 4.64 / 4.258 / 3.722
- Running Current amps (Cooling / Heating): 7.1 / 7.7
- Moisture Removal l/hr: 2.3
- Indoor Sound Pressure Cooling dBA (High / Quiet): 48 / 29
- Indoor Sound Pressure Heating dBA (High / Quiet): 48 / 29
- Outdoor Sound Pressure dBA (Cooling / Heating): 49 / 52
- Outdoor Sound Power dBA: 61
- Air Circulation (Indoor – High Fan) Cooling l/sec: 294
- Air Circulation (Indoor – High Fan) Heating l/sec: 300
- Indoor Unit Dimensions mm (Height x Width x Depth): 280 x 980 x 240
- Indoor Unit Weight kg: 12.50
- Outdoor Unit Dimensions mm (Height x Width x Depth): 716 x 820 x 315
- Outdoor Unit Weight kg: 42.00
- Piping Connects mm Ø (Liquid / Gas): 6.35 / 12.7
- Pipe Length m (Max (Precharged)): 30 (15)
- Max Height Difference m: 25
- Operation Range Cooling °CDB (Min to Max): -10 to 50
- Operation Range Heating °CDB (Min to Max): -15 to 24
- Refrigerant Type: R32
