Mitsubishi Heavy Industries Bronte 9.5kW Inverter Wall Split System Air Conditioner
Specifications
- Indoor Model Unit: DXK33ZRA-WF1
- Outdoor Model Unit: DXC33ZRA-W
- Power Supply: 1-Phase, 240 V, 50 Hz
- Cooling Capacity (T1): 9.5 (2.5 – 10.6)
- Heating Capacity (H1): 10.3 (3.2 – 11.9)
- Heating Capacity (H2): 9.6
- Power Consumption Cooling: 2.56 (0.50 – 3.2)
- Power Consumption Heating: 2.64 (0.60 – 3.7)
- Maximum Power Consumption: 3.80
- Running Current (A) Cooling: 10.8
- Running Current (A) Heating: 11.1
- Inrush / Maximum Current: 11.1 / 17.5
- EER: 3.71
- COP: 3.90
- Sound Power Level (Outdoor): 69 dB(A)
- Sound Pressure Level (Indoor – JIS C9612): 48 / 45 / 40 / 26 dB(A)
- Sound Pressure Level (Outdoor): 57 dB(A)
- Indoor Unit Dimensions: 339 × 1197 × 262 mm
- Outdoor Unit Dimensions: 845 × 970 (+89) × 370 mm
- Indoor Weight: 16.5 kg
- Outdoor Weight: 69 kg
- Airflow Cooling (Indoor): 408 / 355 / 293 / 173
- Airflow Heating (Indoor): 458 / 386 / 318 / 227
- Refrigerant Type: R32 ( 2.0 kg)
- Pre-charged Pipe Length: 15 m
- Liquid Line: Ø 9.52 mm
- Gas Line: Ø 15.88 mm
- Maximum Pipe Length (One Way): 30 m
