Mitsubishi Heavy Industries Bronte 7.1kW Inverter Wall Split System Air Conditioner
Specifications
- Indoor Unit Model: DXK24ZRA-WF1
- Outdoor Unit Model: DXC24ZRA-W
- Power Supply: 1-Phase, 240V, 50Hz
- Cooling Capacity (T1): 7.1 (2.3 – 8.3)
- Heating Capacity (H1): 8.0 (2.0 – 10.9)
- Heating Capacity (H2): 8.1
- Power Consumption Cooling: 1.84 (0.48 – 2.40)
- Power Consumption Heating: 2.02 (0.40 – 3.40)
- Maximum Power Consumption: 3.65
- Running Current (A): Cooling: 7.8
- Running Current (A): Heating: 8.6
- Inrush / Maximum Current: 8.6 / 17.0
- EER: 3.86
- COP: 3.96
- Sound Power Level (Outdoor): 65 dB(A)
- Sound Pressure Level (Indoor – JIS C9612): 43 / 40 / 36 / 24 dB(A)
- Sound Pressure Level (Outdoor): 53 dB(A)
- Indoor Unit Dimensions: 339 × 1197 × 262 mm
- Outdoor Unit Dimensions: 750 × 880 (+88) × 340 mm
- Indoor Weight: 15.5 kg
- Outdoor Weight: 58 kg
- Airflow (L/s) Cooling (Indoor): 342 / 310 / 270 / 174
- Airflow (L/s) Heating (Indoor): 425 / 330 / 288 / 222
- Refrigerant: Type: R32 (1.6 kg)
- Pre-charged Pipe Length: 15 m
- Liquid Line: Ø 6.35 mm
- Gas Line: Ø 15.88 mm
- Maximum Pipe Length (One Way): 30 m
