DAIKIN Alira X 2.2kW Inverter Wall Split System Air Conditioner
Specifications
- INDOOR UNIT: FTXM20YVMA
- OUTDOOR UNIT: RXM20YVMA
- Rated Capacity (Cool): 2.2 kW
- Rated Capacity (Heat): 2.7 kW
- Capacity Range (Cool): 1.0 – 2.8 kW
- Capacity Range (Heat): 1.0 – 4.4 kW
- Indoor Airflow Rate (H) - Cool: 203 L/s
- Indoor Airflow Rate (H) - Heat: 198 L/s
- Indoor Fan Speeds: 5 – steps, quiet and Automatic.
- Star Rating (Residential – ZERL - Cool (Hot/Avg/Cold)): 6 / 5 / 5
- Star Rating (Residential – ZERL - Heat): 3.5 / 3.5 / 3
- Power Supply: 1 Phase, 220–240V, 50Hz
- Power Input (Rated - Cool): 0.42 kW
- Power Input (Rated - Heat): 0.50 kW
- E.E.R / C.O.P (Cool/Heat): 5.29 / 5.40
- TCSPF (Residential) - (Cool (Hot/Avg/Cold)): 7.80 / 5.86 / 6.99
- HSPF (Residential - Heat): 5.34 / 5.13 / 4.76
- A.E.E.R / A.C.O.P (Cool/Heat): 5.20 / 5.33
- Dimensions (HxWxD - Indoor): 299 x 838 x 275 mm
- Dimensions (HxWxD - Outdoor): 550 x 675 x 284 mm
- Weight (Indoor): 12 kg
- Weight (Outdoor): 28 kg
- Compressor Type: Hermetically Sealed Swing Type
- Refrigerant: R32
- Max Pipe Length: 20 m
- Max Level Difference: 15 m
- Pipe Sizes (Liquid): 6.4 mm
- Pipe Sizes (Gas): 9.5 mm
- Outdoor Operating Range (Cool): -10 to 46°C
- Outdoor Operating Range (Heat): -15 to 18°C
- Indoor Sound Level (H/SL - Cool): 39 / 19 dBA
- Indoor Sound Level (H/SL - Heat): 39 / 20 dBA
- Outdoor Sound Level (H/SL - Cool): 46 / 43 dBA
- Outdoor Sound Level (H/SL - Heat): 47 / 44 dBA
- Outdoor EPA Sound Power Level (H) - Cool: 58 dBA
- Outdoor EPA Sound Power Level (H) - Heat: 59 dBA
